JIANGSU WANSHIDA HYDRAULIC MACHINERY CO.، LTD
| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | WANSHIDA |
| إصدار الشهادات: | CE and ISO9001 |
| رقم الموديل: | Y82-25 |
| الحد الأدنى لكمية: | 1 مجموعة |
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | التعبئة الصالحة للإبحار |
| وقت التسليم: | 30 يوما |
| شروط الدفع: | تي/تي |
| القدرة على العرض: | 10 مجموعات / شهر |
| اسم: | كسارة الأسطوانة | نموذج: | Y82-25 |
|---|---|---|---|
| Max.push قوة: | 250kn | سكتة دماغية: | 1000 ملم |
| حجم صندوق الضغط (LxWxH): | 790x790x1060 ملم | حجم كتلة baled (ح): | دقيقة. 60 ملم |
| ضغط النظام الهيدروليكي: | 21 ميجا باسكال | محرك كهربائي: | Y160M-4 |
| قوة: | 11 كيلو واط | الحجم الكلي (LXW XH): | 1150x1500x2950mm |
The Y82-25 Drum Crusher is a compact yet powerful hydraulic machine designed for compressing 200L steel drums. It is widely used in industrial waste recycling, especially in facilities dealing with oil drums, chemical containers, and metal barrels.
With a maximum press force of 250kN, this drum crusher can reduce drum height to as low as 60 mm, significantly decreasing storage space and transportation costs. In many recycling plants, operators often struggle with bulky drums occupying large areas—this machine provides a practical and efficient solution.
Its stable hydraulic system and robust structure ensure reliable operation even under continuous working conditions.
| Item | Parameter |
|---|---|
| Model | Y82-25 |
| Max Push Force | 250 kN |
| Stroke | 1000 mm |
| Chamber Size | 790×790×1060 mm |
| Final Height | Min. 60 mm |
| Hydraulic Pressure | 21 MPa |
| Motor | Y160M-4 |
| Power | 11 kW |
| Overall Size | 1150×1500×2950 mm |
| Weight | 1800 kg |
Q: What type of drums can this machine handle?
A: Mainly 200L steel drums, including oil and chemical barrels.
Q: Can it operate continuously?
A: Yes, the hydraulic system is designed for stable continuous operation.
Q: Is customization available?
A: Yes, we can adjust specifications based on your requirements.
